4K 40/46/47/48/49/55INCH 4K LCD video wall

Product details

1MT720 plus 4K video wall adopt embedded structure design,

2.Use industrial-grade professional DID LCD splicing screen, designed for industrial monitoring and multimedia information display to achieve signal splicing display and achieve signal split display, windowing, superimposing, cross screen, zooming and other special displays.

3:All signals can connected to 256 screen wall through samplex image processor and matrix

4:LVDS 8Bit 60HZVBYONE3840*2160@60HZ adopt Ultra-narrow border design, bilateral seam is less than 5mm, border compensation function, images are real-time display and loss-less after split or enlargement, no delay no training

5: High resolution ratio, unit supports driving 1920X1080 LCD screen

6.Various of splicing mode, Horizontal placement or vertical placement.

7.Automatic check temperature and cooled by fan or healed.

8. Support 7*24 hours, 365 days of continuous power-on, high reliability and high stability, back-light life up to 60,000 hours.

9.Integrate multi-channal video signal type: HDMI, DVI, VGA, CVBS (composite video),support PC image signal and can connect to IT

10.Support the transmission and display in the network, optional internal high definition media player

11. Super wide angle extension technology, the visual angle can reach 178°












Features:

◆ Full hardware architecture, no CPU or operating system;

◆ Menu Language Chinese,English, Multi-lan

◆ Embedded 3D video brightness circuit section, 3D progress scan, 3D digital signal noise reduction, change normal interlaced scan signal PAL/NTSC into progress scan.

◆ Start time less than 8 second, it can guarantee no training

◆ Super silence cooled fan design for longer life of the whole machine

◆ The processor adopts motion detection and compensation calculation, interpolation operation and clutter signal suppression, etc, top process technology.

◆ Adopt ultra-thin tamper-proof out case, radiation-less

◆ Support 7*24 hours, 365 days of continuous power-on, high reliability and high stability, back-light life up to 60,000 hours.




Technical parameter

Panel Size 40inch 46inch 47inch 48inch 49inch 55inch
Pezel 12mm 3.9mm 4.9mm 8mm 2.8mm 1.8mm
Brightness 500cd/m2 700cd/m2 450cd/m2 500cd/m2 500cd/m2 500cd/m2
Max resolution radio   1920*1080 1920*1080 1920*1080 1920*1080 1920*1080 4096*2160
Aspect Ratio 16:09 16:09 16:09 16:09 16:09 16:09
Response Time 8ms 8ms 8ms 8ms 8ms 8ms
Color 16.7M 16.7M 16.7M 16.7M 16.7M 16.7M
Contrast ratio 3000:01:00 3000:01:00 4000:01:00 4000:01:00 3000:01:00 4000:01:00
Max power consumption ≤180W ≤250W ≤300W ≤250W ≤300W ≤400W
Standby power consumption <1W <1W <1W <1W <1W <1W
Pixel Pitch 0.46*0.46 0.63*0.63 0.54*0.54 0.54*0.54 0.63*0.63 0.63*0.63
Voltage input AC100V~240V,50/60Hz
Bachlight life ≥60000 hours
Visual Angle (H/V) 178°/178°/178°/178°
Field frequency 50Hz、60Hz、70Hz
HD TV output 480P、576P、720P、1080P、4K
Packing dimension 、1315.3mmx786.3mmx314.7mm
Installation mode  Wall-mounted/built-in cabinet/floor-standing
Accessories list Power cable/main signal line/232 to RJ45 serial port/install screws(M8*16)/software manual/warranty card/certification card
